High Purity Synthesized CW RF Signal Generator HP Agilent 83712B 10 MHz 20 GHz

High Purity Synthesized CW RF Signal Generator HP Agilent 83712B 10 MHz 20 GHz
High Purity Synthesized CW RF Signal Generator HP Agilent 83712B 10 MHz 20 GHz High Purity Synthesized CW RF Signal Generator HP Agilent 83712B 10 MHz 20 GHz High Purity Synthesized CW RF Signal Generator HP Agilent 83712B 10 MHz 20 GHz

Large Image :  High Purity Synthesized CW RF Signal Generator HP Agilent 83712B 10 MHz 20 GHz

Product Details:
Brand Name: Keysight/Agilent/HP
Model Number: HP Agilent 83712B
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 3-5 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,Western Union,T/T,MoneyGram
Contact Now Chat Now

High Purity Synthesized CW RF Signal Generator HP Agilent 83712B 10 MHz 20 GHz

Description
New / Used: Used Frequency Range: 10 MHz – 20 GHz
Frequency Resolution: 1 KHz (1 Hz With Option 008 Fractional-N Synthesizer) SSB Phase Noise: ≈ –80 DBc/Hz @ 10 GHz, 10 KHz Offset (typical)
Calibrated Output Power: +13 DBm To –110 DBm With Option 1E1 Step Attenuator (typ.; > +14 DBm Below 1 GHz) Harmonics: ≤ –55 DBc Below 20 GHz (typical)
Highlight:

83712b rf generator

,

83712b rf signal generator

,

high purity rf generator

HP Agilent 83712B — 10 MHz – 20 GHz High-Purity Synthesized CW Generator RF Signal Generator
Attribute Value
New / Used Used
Frequency Range 10 MHz – 20 GHz
Frequency Resolution 1 kHz (1 Hz with Option 008 fractional-N synthesizer)
SSB Phase Noise ≈ –80 dBc/Hz @ 10 GHz, 10 kHz offset (typical)
Calibrated Output Power +13 dBm to –110 dBm with Option 1E1 step attenuator (typ.; > +14 dBm below 1 GHz)
Harmonics ≤ –55 dBc below 20 GHz (typical)

The pre-owned Agilent 83712B pairs fully synthesized frequency accuracy with analog-sweep convenience, spanning 10 MHz to 20 GHz in a single 3-U chassis. One-kilohertz tuning steps --or 1 Hz with the fractional-N Option 008--let you drop crystal-clean local oscillators or execute fine scalar sweeps, while -80 dBc/Hz phase-noise performance preserves mixer and noise-figure margins.

Fitted with the 110 dB step attenuator, the generator offers a calibrated +13 dBm to -110 dBm span for PA compression, receiver sensitivity and EMC tasks, and harmonics stay at least 55 dB below the carrier to minimize spurs. Fast band-to-band switching, SCPI/LAN automation and ISO-17025 calibration allow the 83712B to slot directly into R&D or production benches--delivering Keysight-grade signal purity and long-term serviceability at a fraction of new-instrument cost.

High Purity Synthesized CW RF Signal Generator HP Agilent 83712B 10 MHz 20 GHz 0
Contact Us for a Fast Quote

Interested in an HP Agilent 83712B or a similar model?

  • Drop your WhatsApp number or e-mail on our website and we will:
    • Send a tailored quotation and any current promotions.
    • Provide extra photos, test data, and full configuration details.
    • Discuss shipping, duties, warranty, and any other specifics you need.
Looking for other models? Our inventory changes daily--ask for the latest list of spectrum analyzers and RF equipment.

High Purity Synthesized CW RF Signal Generator HP Agilent 83712B 10 MHz 20 GHz 1

Why Choose TESTRO?
  1. Laboratory-Verified Performance
    Every unit ships with an ISO/IEC 17025 calibration certificate bearing the TESTRO Certified seal, so you know the specifications are not just claimed--they're proven.
  2. Total Transparency
    High-resolution teardown photos and a live video test session let you inspect seals, modules, and real-time performance metrics before you pay.
  3. Real Warranty, Real People
    One-year machine warranty, with our engineering team standing by on business days to provide remote assistance for any software or hardware issues.
  4. Global Delivery, Built-In Protection
    DHL lanes--arriving at most destinations in just 3-5 days.
  5. Flexible, Modern Payments
    Choose traditional T/T or wire transfer, credit card.
  6. Open-Door Assurance
    Visit our Shenzhen facility, walk the refurbishment line, and see your equipment on the bench before it leaves our dock.
