Wide Range Analog Signal Generator 6 GHz R&S Signal Generator Rohde & Schwarz R&S SME06

Large Image : Wide Range Analog Signal Generator 6 GHz R&S Signal Generator Rohde & Schwarz R&S SME06

Product Details:

Brand Name:	Rohde & Schwarz
Model Number:	R&S SME06

Payment & Shipping Terms:

Minimum Order Quantity:	1
Delivery Time:	3-5 days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,MoneyGram,Western Union,T/T

Contact Now Chat Now

Wide Range Analog Signal Generator 6 GHz R&S Signal Generator Rohde & Schwarz R&S SME06

Description

New / Used:	Used	Frequency Range:	10 KHz – 6 GHz
RF Output Level:	–135 DBm To +13 DBm, 0.1 DB Step	Level Accuracy:	±1 DB (≤ 2 GHz), ±1.5 DB (2 – 6 GHz)
Phase Noise:	≈ –120 DBc/Hz @ 20 KHz Offset (1 GHz Carrier, Typical)	Modulation Options:	AM, FM, ΦM, Pulse (internal Generators)
Highlight:	wide range analog signal generator , 6 ghz r&s signal generator , analog signal generator 6 ghz

Rohde & Schwarz R&S SME06 — 6 GHz Wide-Range Analog Signal Generator RF Signal Generator

Attribute	Value
New / Used	Used
Frequency Range	10 kHz – 6 GHz
RF Output Level	–135 dBm to +13 dBm, 0.1 dB step
Level Accuracy	±1 dB (≤ 2 GHz), ±1.5 dB (2 – 6 GHz)
Phase Noise	≈ –120 dBc/Hz @ 20 kHz offset (1 GHz carrier, typical)
Modulation Options	AM, FM, ΦM, Pulse (internal generators)

The pre-owned Rohde & Schwarz SME06 delivers clean continuous-wave and analog-modulated signals from 10 kHz up to 6 GHz, covering VHF, UHF and lower C-band devices without external multiplier chains.

A wide -135 dBm to +13 dBm level span, 0.1 dB resolution and better than ±1 dB absolute accuracy enable reliable gain, compression and sensitivity sweeps, while phase-noise around -120 dBc/Hz at 20 kHz offset protects stringent ACLR and blocking budgets. Built-in low-distortion AM, FM, phase and pulse modulators eliminate extra generators, and rear-panel blanking allows fast list-mode hopping for automated production lines.

Delivered fully tested, freshly calibrated and firmware-current, this SME06 offers immediate bench deployment and substantial capital savings without compromising the signal purity, reliability or SCPI automation expected of Rohde & Schwarz equipment.

Interested in Rohde & Schwarz R&S SME06 or a similar model?

Drop your WhatsApp number or e-mail on our website and we will:
- Send a tailored quotation and any current promotions.
- Provide extra photos, test data, and full configuration details.
- Discuss shipping, duties, warranty, and any other specifics you need.

Looking for other models? Our inventory changes daily--ask for the latest list of spectrum analyzers and RF equipment.

Why Choose TESTRO?

Laboratory-Verified Performance
Every unit ships with an ISO/IEC 17025 calibration certificate bearing the TESTRO Certified seal, so you know the specifications are not just claimed--they're proven.
Total Transparency
High-resolution teardown photos and a live video test session let you inspect seals, modules, and real-time performance metrics before you pay.
Real Warranty, Real People
One-year machine warranty, with our engineering team standing by on business days to provide remote assistance for any software or hardware issues.
Global Delivery, Built-In Protection
DHL lanes--arriving at most destinations in just 3-5 days.
Flexible, Modern Payments
Choose traditional T/T or wire transfer, credit card.
Open-Door Assurance
Visit our Shenzhen facility, walk the refurbishment line, and see your equipment on the bench before it leaves our dock.
