Keysight N9020B Mxa Signal Analyzer 50 GHz Wide Bandwidth Used

Keysight N9020B Mxa Signal Analyzer 50 GHz Wide Bandwidth Used
Keysight N9020B Mxa Signal Analyzer 50 GHz Wide Bandwidth Used Keysight N9020B Mxa Signal Analyzer 50 GHz Wide Bandwidth Used Keysight N9020B Mxa Signal Analyzer 50 GHz Wide Bandwidth Used

Large Image :  Keysight N9020B Mxa Signal Analyzer 50 GHz Wide Bandwidth Used

Product Details:
Brand Name: Keysight/Agilent/HP
Model Number: Keysight N9020B
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 3-5 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,Western Union,T/T,MoneyGram
Contact Now Chat Now

Keysight N9020B Mxa Signal Analyzer 50 GHz Wide Bandwidth Used

Description
New / Used: Used Frequency Range: 10 Hz – 50 GHz (Option 550)
Analysis Bandwidth: 160 MHz With Option B1X (25 MHz Standard) Phase Noise: –114 DBc/Hz @ 10 KHz Offset, 1 GHz Carrier (typ.)
DANL (Preamp On): –172 DBm/Hz @ 1 Hz RBW, 1 GHz, Pre-amp On (typ.) Interfaces / Options: USB 3.0, 1 / 10 GbE LAN, GPIB; 160 MHz Real-time RTSA (Option RT1), Vector-signal Analysis Apps
Highlight:

mxa signal analyzer 50 GHz

,

Wide Bandwidth keysight signal analyzer

,

Keysight N9020B mxa signal analyzer

Keysight N9020B MXA — 50 GHz Wide-Bandwidth Signal Analyzer Signal Spectrum Analyzer
Attribute Value
New / Used Used
Frequency Range 10 Hz – 50 GHz (Option 550)
Analysis Bandwidth 160 MHz with Option B1X (25 MHz standard)
Phase Noise –114 dBc/Hz @ 10 kHz offset, 1 GHz carrier (typ.)
DANL (Preamp On) –172 dBm/Hz @ 1 Hz RBW, 1 GHz, pre-amp on (typ.)
Interfaces / Options USB 3.0, 1 / 10 GbE LAN, GPIB; 160 MHz real-time RTSA (Option RT1), vector-signal analysis apps
Product Description
The pre-owned Keysight N9020B MXA couples fundamental-mixing coverage from 10 Hz to 50 GHz with up to 160 MHz instantaneous capture, letting engineers verify 5 G FR1, Wi-Fi 6E and radar signals in a single sweep. A -114 dBc/Hz phase-noise floor and -172 dBm sensitivity expose spurs that threaten tight EVM and ACLR budgets, while the 160 MHz real-time option guarantees 100 % probability-of-intercept for micro-second transients.
High-speed 10 GbE streaming, SCPI automation and field-installable measurement apps streamline both R & D debug and high-volume calibration, delivering Keysight accuracy and reliability at a fraction of new-instrument cost.
Keysight N9020B Mxa Signal Analyzer 50 GHz Wide Bandwidth Used 0
Contact Us for a Fast Quote

Interested in Keysight N9020B MXA -- 50 GHz Wide-Bandwidth Signal Analyzer or a similar model?

  • Drop your WhatsApp number or e-mail on our website and we will:
    • Send a tailored quotation and any current promotions.
    • Provide extra photos, test data, and full configuration details.
    • Discuss shipping, duties, warranty, and any other specifics you need.

Looking for other models? Our inventory changes daily--ask for the latest list of spectrum analyzers and RF equipment.


Keysight N9020B Mxa Signal Analyzer 50 GHz Wide Bandwidth Used 1

Frequently Asked Questions (FAQ)
1/ Performance Assurance

Every unit is calibrated at an ISO/IEC 17025 accredited laboratory. The original calibration certificate, marked TESTRO Certified, is linked to the unit's serial number and included in the shipment.

2/ Integrity of Internal Components
  • A set of high-resolution teardown photographs showing seals, fasteners, and all critical modules.
  • A live video session in which an engineer demonstrates gain-linearity, noise-floor, and spurious-response tests in real time. All recordings remain in our cloud archive for the life of the product.
3/ Warranty & Technical Support
  • One-year transferable warranty.
  • Our in-house engineering team is available on business days to provide remote software troubleshooting or hardware-assembly guidance.
4/ International Shipping Protection
  • Custom flight case built from aviation-grade plywood with triple-layer anti-vibration foam.
  • Shock- and tilt-indicator labels on every crate.
  • Preferred carrier: DHL, delivery in 3-5 days to major destinations.
5/ Payment Terms

We accept T/T, wire transfer, credit card.

6/ On-Site Inspection

Customers are welcome to visit our Shenzhen warehouse and refurbishment line to inspect calibration benches, burn-in racks, and inventory.
