1020 V / 20 A Multi Product Calibrator Fluke Calibrator 5520a

1020 V / 20 A Multi Product Calibrator Fluke Calibrator 5520a
1020 V / 20 A Multi Product Calibrator Fluke Calibrator 5520a 1020 V / 20 A Multi Product Calibrator Fluke Calibrator 5520a

Large Image :  1020 V / 20 A Multi Product Calibrator Fluke Calibrator 5520a

Product Details:
Brand Name: Fluke
Model Number: Fluke 5520A
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 3-5 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,Western Union,T/T,MoneyGram
Contact Now Chat Now

1020 V / 20 A Multi Product Calibrator Fluke Calibrator 5520a

Description
New / Used: Used DC Voltage Output: 0 V – ±1020 V, Best 1-year Accuracy ≈ 11 Ppm Of Setting
AC Voltage Range & Bandwidth: 1 MV – 1020 V, 10 Hz – 500 KHz Fundamental DC / AC Current Output: 0 – ±20.5 A Direct (extendable To 50 A With External 5220A/52120A Amplifier)
Resistance Range: 0 Ω – 100 MΩ, ≤ 15 Ppm Uncertainty At 1 KΩ Remote Interfaces: IEEE-488 (GPIB) & RS-232; Fully Supported By MET/CAL® Automation Software
Highlight:

1020 v / 20 a multi product calibrator

,

1020 v / 20 a fluke calibrator 5520a

,

11 ppm fluke calibrator 5520a

Fluke 5520A — 1020 V / 20 A Multi-Product Calibrator Multi Function Calibrator



The pre-owned Fluke 5520A combines precision sources for voltage, current and resistance in a single chassis that reaches ±1020 V, ±20 A and 100 MΩ. With typical 11 ppm DC accuracy and wide-band AC outputs to 500 kHz, it delivers a 4∶1 test-uncertainty ratio when calibrating 6½-digit bench meters, handheld DMMs, clamp meters (via external current booster) and power analyzers. Programmable harmonics, phase control and built-in MET/CAL® procedures slash setup time, while GPIB/RS-232 connectivity lets the calibrator drop straight into automated systems. Supplied fully tested, freshly calibrated and firmware-current, each unit provides traceable Fluke performance and immediate cost savings compared with new equipment.





1020 V / 20 A Multi Product Calibrator Fluke Calibrator 5520a 0





Contact TESTRO for a Fast Quote

Interested in Fluke 5520A or a similar model?



  • Drop your WhatsApp number or e-mail on our website and we will:



    • Send a tailored quotation and any current promotions.

    • Provide extra photos, test data, and full configuration details.

    • Discuss shipping, duties, warranty, and any other specifics you need.



Looking for other models? Our inventory changes daily—ask for the latest list of spectrum analyzers and RF equipment.





1020 V / 20 A Multi Product Calibrator Fluke Calibrator 5520a 1







TESTRO Advantages

  1. Laboratory-Verified Performance – Every unit ships with an ISO/IEC 17025 calibration certificate (TESTRO Certified) tied to its serial number.

  2. Full Internal Transparency – High-resolution teardown photos plus a live video test (gain-linearity, noise-floor, spurious response); recordings are stored for the product’s lifetime.

  3. Warranty & Technical Support – One-year warranty and weekday remote assistance from the in-house engineering team for both software and hardware issues.

  4. Secure, Rapid Shipping – Aviation-grade flight case with triple-layer anti-vibration foam and shock/tilt indicators; priority DHL delivery in 3–5 days to major destinations.

  5. Flexible Payment Options – Accepts T/T, wire transfer, credit card.

  6. On-Site Inspection Welcome – Customers may visit the Shenzhen warehouse and refurbishment line to view calibration benches, burn-in racks, and inventory.
