Product Details:
Brand Name: Keysight/Agilent/HP
Model Number: Keysight/Agilent E9304A
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 3-5 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,Western Union,T/T,MoneyGram
Contact Now Chat Now

E9304A 6 GHz Agilent Power Sensor Wide Dynamic Range Power Sensor

Description
New / Used: Used Frequency Range: 9 KHz – 6 GHz (Option H18 Extends To 18 GHz)
Power Range: –60 DBm To +20 DBm (80 DB Span) Measurement Speed: Up To 400 Corrected Readings /s With E4416A/N191x Meters
Connector Type: Type-N Male, 50 Ω — On-board EEPROM Auto-loads Cal Factors Compatible Meters: Keysight EPM, EPM-P & P-Series (SCPI)
Highlight:

agilent power sensor wide dynamic

,

e9304a agilent power sensor

,

e9304a power sensor agilent

Agilent E9304A — 6 GHz Wide-Dynamic-Range Power Sensor
Attribute Value
New / Used Used
Frequency Range 9 kHz – 6 GHz (Option H18 extends to 18 GHz)
Power Range –60 dBm to +20 dBm (80 dB span)
Measurement Speed Up to 400 corrected readings /s with E4416A/N191x meters
Connector Type Type-N male, 50 Ω — on-board EEPROM auto-loads cal factors
Compatible Meters Keysight EPM, EPM-P & P-Series (SCPI)
The pre-owned Agilent E9304A diode sensor delivers true-RMS average-power measurements from 9 kHz to 6 GHz across a wide -60 dBm to +20 dBm dynamic range, making one probe sufficient for VLF EMI work through S-band radios. Its dual-path architecture avoids range-switch glitches while sustaining up to 400 corrected readings per second for fast gain, compression or VSWR sweeps. An EEPROM in the Type-N body stores calibration, so Keysight EPM-/P-series meters load factors instantly, tightening uncertainty budgets and eliminating manual tables. Refurbished units ship ISO-17025-calibrated with current firmware, giving you Keysight-grade accuracy, rugged connectivity and long-term serviceability at a fraction of new-sensor cost.
E9304A 6 GHz Agilent Power Sensor Wide Dynamic Range Power Sensor 0
Contact TESTRO for a Fast Quote

Interested in an Agilent E9304A -- 6 GHz Wide-Dynamic-Range Power Sensor or a similar model?

  • Drop your WhatsApp number or e-mail on our website and we will:
    • Send a tailored quotation and any current promotions.
    • Provide extra photos, test data, and full configuration details.
    • Discuss shipping, duties, warranty, and any other specifics you need.
Looking for other models? Our inventory changes daily--ask for the latest list of spectrum analyzers and RF equipment.

E9304A 6 GHz Agilent Power Sensor Wide Dynamic Range Power Sensor 1
TESTRO Advantages
  • Laboratory-Verified Performance - Every unit ships with an ISO/IEC 17025 calibration certificate (TESTRO Certified) tied to its serial number.
  • Full Internal Transparency - High-resolution teardown photos plus a live video test (gain-linearity, noise-floor, spurious response); recordings are stored for the product's lifetime.
  • Warranty & Technical Support - One-year warranty and weekday remote assistance from the in-house engineering team for both software and hardware issues.
  • Secure, Rapid Shipping - Aviation-grade flight case with triple-layer anti-vibration foam and shock/tilt indicators; priority DHL delivery in 3-5 days to major destinations.
  • Flexible Payment Options - Accepts T/T, wire transfer, credit card.
  • On-Site Inspection Welcome - Customers may visit the Shenzhen warehouse and refurbishment line to view calibration benches, burn-in racks, and inventory.
