2.7 GHz RF Communications Test Set Multi Standard Wireless Test Set Agilent E5515C 8960

2.7 GHz RF Communications Test Set Multi Standard Wireless Test Set Agilent E5515C 8960
2.7 GHz RF Communications Test Set Multi Standard Wireless Test Set Agilent E5515C 8960 2.7 GHz RF Communications Test Set Multi Standard Wireless Test Set Agilent E5515C 8960 2.7 GHz RF Communications Test Set Multi Standard Wireless Test Set Agilent E5515C 8960

Large Image :  2.7 GHz RF Communications Test Set Multi Standard Wireless Test Set Agilent E5515C 8960

Product Details:
Brand Name: Keysight/Agilent/HP
Model Number: Agilent E5515C 8960
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 3-5 days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,Western Union,T/T,MoneyGram
Contact Now Chat Now

2.7 GHz RF Communications Test Set Multi Standard Wireless Test Set Agilent E5515C 8960

Description
New / Used: Used Frequency Range: 292 MHz – 2.7 GHz (covers GSM, W-CDMA & Cdma2000 Bands)
RF Signal-Generator Level: –110 DBm To –13 DBm With Modulation, 0.1 DB Step Channel-Power Accuracy: ±1 DB (typ., 200 KHz–5 MHz BW)
VSWR: < 1.2:1 (400 – 2000 MHz) Dimensions / Weight: 426 × 279 × 533 Mm, 27.7 Kg (61 Lb)
Highlight:

2.7 GHz RF Communications Test Set

,

Multi Standard Wireless Test Set

,

Wireless Test Set E5515C 8960

Agilent E5515C 8960 — 2.7 GHz Multi-Standard Wireless Test Set RF Communications Test Set
Attribute Value
New / Used Used
Frequency Range 292 MHz – 2.7 GHz (covers GSM, W-CDMA & cdma2000 bands)
RF Signal-Generator Level –110 dBm to –13 dBm with modulation, 0.1 dB step
Channel-Power Accuracy ±1 dB (typ., 200 kHz–5 MHz BW)
VSWR < 1.2:1 (400 – 2000 MHz)
Dimensions / Weight 426 × 279 × 533 mm, 27.7 kg (61 lb)

A pre-owned Agilent E5515C brings 292 MHz-to-2.7 GHz RF generation, analysis and network emulation into one 61-lb chassis, letting you run GSM/GPRS/EDGE, W-CDMA/HSPA and cdma2000 device tests without a stack of boxes. The -110 dBm sensitivity, -13 dBm leveled output and ±1 dB channel-power accuracy support both handset low-level calibration and base-station PA alignment, while built-in spectrum, modulation and audio analyzers streamline debug.

Buying refurbished slashes cap-ex and lead-time; units can ship ISO-17025-calibrated with the latest 8960 firmware, preserving Agilent reliability, SCPI/LAN automation and future application-license upgrades at a fraction of new-instrument cost.

2.7 GHz RF Communications Test Set Multi Standard Wireless Test Set Agilent E5515C 8960 0
Contact TESTRO for a Fast Quote

Interested in an Agilent E5515C -- 2.7 GHz Multi-Standard Wireless Test Set or a similar model?

  • Drop your WhatsApp number or e-mail on our website and we will:
    • Send a tailored quotation and any current promotions.
    • Provide extra photos, test data, and full configuration details.
    • Discuss shipping, duties, warranty, and any other specifics you need.
Looking for other models? Our inventory changes daily--ask for the latest list of spectrum analyzers and RF equipment.

2.7 GHz RF Communications Test Set Multi Standard Wireless Test Set Agilent E5515C 8960 1

TESTRO Advantages
1. Laboratory-Verified Performance - Every unit ships with an ISO/IEC 17025 calibration certificate (TESTRO Certified) tied to its serial number.
2. Full Internal Transparency - High-resolution teardown photos plus a live video test (gain-linearity, noise-floor, spurious response); recordings are stored for the product's lifetime.
3. Warranty & Technical Support - One-year warranty and weekday remote assistance from the in-house engineering team for both software and hardware issues.
4. Secure, Rapid Shipping - Aviation-grade flight case with triple-layer anti-vibration foam and shock/tilt indicators; priority DHL delivery in 3-5 days to major destinations.
5. Flexible Payment Options - Accepts T/T, wire transfer, credit card.
6. On-Site Inspection Welcome - Customers may visit the Shenzhen warehouse and refurbishment line to view calibration benches, burn-in racks, and inventory.
